Hollow shaft sensor GS04
System component for AP10S, MA503/2, MA504/1
- Rotatively measuring sensor with magnetic scanning
- Pluggable connection to AP10S, AP20S, MA503/2, MA504/1 position indicators
- Easy hollow-shaft mounting, max. Ø 20 mm
- IP65 protection class
Technical drawing
Technical Specifications
Mechanical data
Electrical data
System data
Ambient conditions
Feature
Technical Specifications
Enhancement
shaft
rustproof stainless steel
Housing
plastic
Color
black, RAL 9005
Speed
≤600
min-1
Cable sheath
PUR
E15 type of connection
PVC
E16 type of connection
Cable bending radius
≥52
mm
permanently/flexibly laid (E15 type of connection)
>17
mm
hard-wired (E16 type of connection)
Feature
Technical Specifications
Enhancement
Operating voltage
supply via downstream electronic unit
Type of connection
M8 plug connector
6-pole, 1x pin (E15 type of connection)
flat connector
8-pole, 1x pin (E16 type of connection)
Feature
Technical Specifications
Enhancement
Scanning
magnetic
polewheel with 18 poles of 5 mm each
Resolution
depending on downstream electronic unit
Measuring range
depending on downstream electronic unit
Feature
Technical Specifications
Enhancement
Ambient temperature
0 … 60 °C
Storage temperature
-20 … 70 °C
Relative humidity
condensation inadmissible
EMC
EN 61000-6-2
interference resistance / immission
EN 61000-6-4
emitted interference / emission
Protection category
IP65
EN 60529
Purchase order
Product configuration
Feature
Select specifications
Enhancement
Select your specifications:
hollow shaft/
diameter
20
Type of connection
E15
suitable for AP04S and AP10S
suitable for MA503/2 and MA504/1
Cable length
00.5
m, in intervals of 0.5 m
Accessories
Scope of delivery
- GS04
- Installation Instructions
