Incremental encoder IV2800
Optical miniature rotary encoder, max. 1024 pulses/revolution
The optical incremental rotary encoder IV2800 is very tough and particularly impressive in applications in confined spaces. With its robust bearings, short circuit-proof outputs and effective strain relief, it offers reliability in the most restricted environments!
- Small design, Ø 28 mm
- Resolutions of max. 1024 pulses/revolution
- Robust bearing construction
- Short circuit-proof outputs
Ben
King
Inside Sales
August
Meyers
Manager Business Unit Mobile Automation
Technical drawing
Technical Specifications
Mechanical data
Electrical data
System data
Ambient conditions
Feature
Technical Specifications
Enhancement
Weight
~0.06
kg
shaft
rustproof stainless steel
Housing
aluminum
Speed
≤12000
min-1
Moment of inertia
~0.1 x 10-6 kgm2
Starting torque
0.01
Nm
at 20 °C
Shaft load rating
10
N
radial
20
N
axial
Cable sheath
PVC
~Ø 4.5 mm
Cable bending radius
25
mm
static
75
mm
dynamic
Ausgangsschaltung PP
Feature
Technical Specifications
Enhancement
Operating voltage
8 … 30 V DC
reverse polarity protected, the power-supply unit corresponds to Class 2 (UL 1310)
Current consumption
50
mA
typical
without load
Output signal level high
≥UB - 3.0 V
short-circuit proof
Output signal level low
≤0.5
V
short-circuit proof
Pulse frequency
≤160
kHz
Load
±50
mA
max. adm.
Type of connection
open cable end
Ausgangsschaltung OP
Feature
Technical Specifications
Enhancement
Operating voltage
8 … 30 V DC
reverse polarity protected, the power-supply unit corresponds to Class 2 (UL 1310)
Current consumption
50
mA
typical
without load
Output signal level high
≥UB - 3.0 V
short-circuit proof
Output signal level low
≤0.5
V
short-circuit proof
Pulse frequency
≤160
kHz
Load
±50
mA
max. adm.
Type of connection
open cable end
Ausgangsschaltung LD5
Feature
Technical Specifications
Enhancement
Operating voltage
5 V DC ±5 %
reverse polarity protected, the power-supply unit corresponds to Class 2 (UL 1310)
Current consumption
≤90
mA
without load
Output signal level high
≥2.5
V
short-circuit proof
Output signal level low
≤0.5
V
short-circuit proof
Pulse frequency
≤300
kHz
Load
±20
mA
max. adm.
Type of connection
open cable end
Signal image
Feature
Technical Specifications
Enhancement
Approval
UL
UL 61010-1, File No. E503367
Kenndaten funktionale Sicherheit
Feature
Technical Specifications
Enhancement
MTTFd
54.2
Year(s)
Feature
Technical Specifications
Enhancement
Ambient temperature
-20 … 85 °C
EMC
EN 61000-6-2
interference resistance / immission
EN 61000-6-3
emitted interference / emission
Safety regulations
UL 61010-1
indoor use, outdoor use possible, not intended for use involving direct exposure to UV light.
Protection category
IP65 (housing side)
EN 60529 (protection type not yet reviewed by UL)
IP64 (shaft side)
EN 60529 (protection type not yet reviewed by UL)
Shock resistance
1000 m/s2, 6 ms
EN 60068-2-27
Vibration resistance
100 m/s2, 10 … 2000 Hz
EN 60068-2-6
More information
pin assignment
|
Signal |
Cable color PP |
Cable color OP, LD |
|
GND |
white |
white |
|
+UB |
brown |
brown |
|
A |
green |
green |
|
/A |
yellow |
|
|
B |
yellow |
gray |
|
/B |
Pink |
|
|
0 |
gray |
blue |
|
/0 |
red |
Purchase order
Product configuration
Feature
Select specifications
Enhancement
Select your specifications:
pulses/
revolution
16
position of electrical connection
A
Cable length
00.5
in m
Output circuit
PP
shaft diameter
5x10
with area
Accessories
Scope of delivery
- IV2800
- Quick Start Guide
