Translation module ASA110H
Quasi-absolute, battery-buffered translation module
- Max. resolution 0.2 μm (LD)
- Repeat accuracy ±5 μm
- SSI or RS485 interface
- Scale MBA110
- Reading distance ≤0.4 mm
- Compact, absolutely measuring unit with hard-wired sensor
- Maintenance-free backup battery
- Option: digital LD interface
- Option: analog 1 VSS interface (period length 1 mm)
Note
The internal translation module can generate fast counting pulses, the lengths of wich are limited by the pulse interval. The downstream electronics must be adjusted accordingly. Select the pulse interval in advance, if necessary.
Technical drawing
Technical Specifications
Travel speed
Travel speed Vmax [m/s] |
||||||
Resolution [µm] |
0.5 |
0.80 |
0.32 |
0.15 |
0.06 |
0.02 |
1 |
4.00 |
1.60 |
0.72 |
0.32 |
0.12 |
|
10 |
8.00 |
8.00 |
7.20 |
3.20 |
1.25 |
|
12.5 |
8.00 |
8.00 |
8.00 |
4.00 |
1.60 |
|
Pulse interval [μs] |
0.2 |
0.5 |
1.1 |
2.5 |
6.3 |
|
Counting frequency [kHz] |
1250.00 |
500.00 |
230.00 |
100.00 |
40.00 |
|
6 |
2 |
3 |
3 |
3 |
3 |
3 |
Note
The internal translation module can generate fast counting pulses, the lengths of wich are limited by the pulse interval. The downstream electronics must be adjusted accordingly. Select the pulse interval in advance, if necessary.
More information
pin assignment
X1 plug
SSI |
SSI + 2xLD |
PIN |
nc |
A |
1 |
nc |
/A |
2 |
+24 V DC |
+24 V DC |
3 |
0 V |
0 V |
4 |
nc |
nc |
5 |
nc |
nc |
6 |
SSI_DATA |
SSI_DATA |
7 |
/SSI_DATA |
/SSI_DATA |
8 |
nc |
B |
9 |
nc |
/B |
10 |
nc |
nc |
11 |
SSI_GND |
SSI_GND |
12 |
nc |
nc |
13 |
SSI_CLK |
SSI_CLK |
14 |
/SSI_CLK |
/SSI_CLK |
15 |
X2 plug
RS485 |
RS485 + LD |
PIN |
nc |
A |
1 |
nc |
B |
2 |
nc |
nc |
3 |
+24 V DC |
+24 V DC |
4 |
0 V |
0 V |
5 |
nc |
/A |
6 |
nc |
/B |
7 |
DÜA |
DÜA |
8 |
DÜB |
DÜB |
9 |
X3 plug
≤ 1 VSS |
PIN |
sin |
1 |
/sin |
2 |
cos |
3 |
nc |
4 |
nc |
5 |
nc |
6 |
ANA_GND |
7 |
/cos |
8 |
nc |
9 |
Hint for mounting
A, Sensor/tape reading distance |
≤0.4 mm |
B, Lateral offset |
±0.5 mm |
C, Alignment error |
±1° |
D, Longitudinal inclination |
±1° |
E, Lateral inclination |
±2° |
System components
Purchase order
Product configuration
Feature
Select specifications
Enhancement
Cable length
01.0
digital interface
LD
digital resolution
1
Pulse interval
0.2
Accessories
Scope of delivery
- ASA110H
- Installation Instructions
- Sensor fastening set
