Geared potentiometer GP09
Robust housing with through hollow shaft
- Resistant to external influences
- Through hollow shafts up to ø20 mm
- Adaptation to various measurement distances owing to a wide range of gear ratios
- Integrated slip clutch to protect the potentiometer
- Compact design
- Potentiometer, power or voltage output
- IP68 protection class with oil filling possible
- Easy mounting
Ben
King
Inside Sales
August
Meyers
Manager Business Unit Mobile Automation
Technical drawing
Technical Specifications
Mechanical data
Electrical data
System data
Ambient conditions
Feature
Technical Specifications
Enhancement
shaft
rustproof stainless steel
Housing
zinc die-cast
Gear ratio
0.2 … 244
Speed
≤500
min-1
depending on transmission
Shaft load rating
≤400
N
radial
≤150
N
axial
Potentiometer service life
1 x 106 rotation(s)
Geber Potentiometer Typ 01, 1 Wendel
Feature
Technical Specifications
Enhancement
Power rating
1
W
at 70 °C
≤30 V
resistance
1
kΩ
,
5
,
10
kΩ
Resistance tolerance
±10
%
Standard terminal resistance
0.5
%
Linearity tolerance
±1
%
Design
hybride
Geber Potentiometer Typ 02, 10 Wendel
Feature
Technical Specifications
Enhancement
Power rating
2
W
at 70 °C
≤30 V
resistance
1
kΩ
,
5
,
10
kΩ
Resistance tolerance
±5
%
Standard terminal resistance
0.2
%
Linearity tolerance
±0.25
%
Design
wire
Geber Potentiometer Typ 03/0.1, 10 Wendel
Feature
Technical Specifications
Enhancement
Power rating
2
W
at 70 °C
≤30 V
resistance
1
kΩ
,
5
,
10
kΩ
Resistance tolerance
±5
%
Standard terminal resistance
0.2
%
Linearity tolerance
±0.1
%
Design
hybride
Messwandler, Stromausgang
Feature
Technical Specifications
Enhancement
Operating voltage
24 V DC ±20 %
Output current
4 … 20 mA
at load 500 Ω
Messwandler, Spannungsausgang
Feature
Technical Specifications
Enhancement
Operating voltage
24 V DC ±20 %
Output voltage
0 … 10 V
Feature
Technical Specifications
Enhancement
Measuring range
340° ±5°
(mechanical full-length)
potentiometer type 01
3600° +10°
potentiometer types 02, 03/0.1
Feature
Technical Specifications
Enhancement
Ambient temperature
-20 … 80 °C
without oil fill
-10 … 80 °C
with oil fill
Relative humidity
condensation inadmissible
EMC
EN 61000-6-2
interference resistance / immission
EN 61000-6-4
emitted interference / emission
Protection category
IP52, IP65, IP68
EN 60529
More information
pin assignment
without transducer
|
Signal |
Cable color E1 |
PIN E12 |
|
Po |
white |
1 |
|
S |
green |
2 |
|
Pe |
brown |
3 |
|
nc |
- |
4 |
MWI transducer
|
Signal |
Cable color E1 |
PIN E12 |
|
I- |
white |
1 |
|
nc |
- |
2 |
|
I+ |
brown |
3 |
|
nc |
- |
4 |
MWU transducer
|
Signal |
PIN E12 |
|
|
GND |
white |
1 |
|
Uout |
green |
2 |
|
+24 V DC |
Braun |
3 |
|
nc |
- |
4 |
Purchase order
Gear ratio calculation
Product configuration
Feature
Select specifications
Enhancement
Select your specifications:
Gear ratio
0.184
torque pin/
form
A
potentiometer type
01
analog output
MWI
Sense of rotation
<leer>
only for P01, P05, or P10 analog output
only for MWI or MWU analog output
only for MWI or MWU analog output
Type of connection
E1
Cable length
00.3
00.3
20.0 m, in intervals of 0.1 m
Protection category
IP52
with oil filling, against condensation
number of revolutions
<leer>
except with IP68
only with IP68 type of protection and analog output MWI, MWU
only with IP68 type of protection and analog output MWI, MWU
Accessories
Additional Accessories
Order key
Mating connector, 4-pole, socket
83526
Scope of delivery
- GP09
- Installation Instructions
